LR-ZH500CP

• Type: LR-Z Series High-Power Reflective CMOS Laser Sensor (Background Tuning Distance-Setting Type) • Core Specs: 35-500mm detection range, PNP output, 4-pin M8 connector, 10-30 VDC power supply (10% ripple max), 450 mW max power consumption, 1.5ms/10ms/50ms selectable response time, red laser (660 nm, Class 2), SUS316L housing, IP67 protection, 22.5mm width, DIN rail mountable • Function: Delivers stable long-distance detection up to 500mm with 2 million-fold dynamic range, capable of reliably detecting black, metallic, and transparent objects; background tuning feature minimizes interference from surrounding objects • Application: Ideal for industrial automation scenarios requiring non-contact object detection, including assembly lines, packaging machinery, material handling systems, and quality inspection processes
